Marantz NR1510
SLIM 5.2 CHANNEL 4K ULTRA HD AV RECEIVER WITH HEOS BUILT-IN

Channels    5.2
Power Output per Channel    2-Channel Driven:
50 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD
60 W at 6 Ohms / 1 kHz / 0.7% THD
1-Channel Driven:
100 W at 6 Ohms / 1 kHz / 10% THD
Frequency Response    10 Hz to 100 kHz +1/-3 dB (Direct Mode)
Audio Processing
DTS Compatibility    DTS-HD Master Audio
Dolby Compatibility    Dolby TrueHD
Auro 3D Support    No
Supported File Formats    AAC, ALAC, FLAC, MP3, WAV, WMA
Video
HDR Compatibility    HDR10, Dolby Vision, Hybrid Log Gamma
Pass-Through Support    4K60p 4:4:4 (BT.2020)
Connectivity
Rear A/V Inputs    5 x HDMI
3 x RCA Composite
4 x Stereo RCA (Phono) with Ground Screw
1 x Optical TOSLINK
1 x Digital Coaxial
Rear A/V Outputs    1 x HDMI
1 x RCA Composite
1 x Stereo RCA Pre-Out
2 x RCA Subwoofer Pre-Out
1 x 1/4'' / 6.35 mm Headphone
Front I/O    1 x HDMI
1 x USB Type-A
Other Rear I/O    2 x Bluetooth/Wi-Fi Antenna Terminal
1 x RJ45 (Ethernet) Input
1 x AM Antenna Terminal
1 x FM Antenna Terminal
1 x 1/8'' / 3.5 mm (IR) Input
1 x RCA (Remote) Input
1 x RCA (Remote) Output
1 x 1/8'' / 3.5 mm (Setup Mic) Input
Speaker Connectors    5 x Binding Post Pairs
HDCP Support    Version 2.2
Audio Return Channel (ARC)    Yes, eARC
HDMI CEC    Yes
Input Sensitivity    Line: 130 mV
Phono: 2.5 mV
Signal to Noise Ratio    Line: 98 dB (A-Weighted / Direct Mode)
Phono: 74 dB
Wireless Connectivity
Wi-Fi    Wi-Fi 4 (802.11n); Dual-Band (2.4 & 5 GHz)
Wireless Security    AES, TKIP, WEP 128, WEP 64, WPA-PSK, WPA2-PSK
Bluetooth    4.1
Bluetooth Profiles    A2DP 1.2, AVRCP 1.5
Supported Audio Codecs    SBC
Bluetooth Range    98.4' / 30 m
Wireless Audio Protocols    AirPlay 2
Tuner Section
Tuner Type    AM, FM
Radio Frequencies    AM: 520 to 1710 kHz
FM: 87.5 to 107.9 MHz
Sensitivity    AM Effective: 18 µV
FM Effective: 1.2 µV / 12.8 dBf
FM Mono at 50 dB: 2.8 µV / 20.2 dBf
Power
AC Input Power    240 VAC, 50/60 Hz
Power Consumption    Active: 180 W
Standby: 0.2 W
CEC Standby: 0.5 W
Physical
Dimensions (W x H x D)    17.3 x 4.1 x 14.9'' / 43.9 x 10.4 x 37.8 cm (Antenna Down)
17.3 x 6.9 x 14.9'' / 43.9 x 17.5 x 37.8 cm (Antenna Up)
17.3 x 4.1 x 14.5'' / 43.9 x 10.4 x 36.8 cm (Antenna Removed)
Weight    18.1 lb / 8.2 kg
